The Arcam AVR20 offers 9.1.6 Atmos and DTS:X decoding with 90WPC (7 channels driven into 8 ohms), DIRAC, HDCP2.2, HDMI 2.0b. It is a feature-packed receiver that really does deliver superb surround sound performance as well.
Stunning Realism, Immersive Sound
The AVR20 is a high-performance audio/visual receiver that delivers stunning realism for the ultimate home cinema experience. With an impressive 16-channel surround solution and featuring all the latest CODECs from Dolby, DTS and IMAX Enhanced, the AVR20 exemplifies sound quality and engineering excellence. The AVR20 features the efficient class AB amplification for a level of transparency that delivers the most captivating sound. Audiophile listening experiences are optimised with full 16-channel Dirac calibration on board as well as simple streaming with a mobile device using the native app of choice via Apple Airplay2 or Google Chromecast.
If you want this amp DIRAC calibrated as well, please email for a quotation. Price is system and distant dependent.
• Dolby Atmos & DTS:X 9.1.6 decoding
• 4K (UHD) HDMI2.0b with HDCP2.2
• 7 HDMI inputs, 3 HDMI outputs, eARC compatible
• Dirac Live® for Arcam room correction
• ESS 9026PRO audiophile DAC
• Class G power amplification - Uses toroidal transformer
• Wifi / Ethernet, RS232 and IR control
• Google Cast/UPnP capability for streaming audio
• Free MusicLife iOS UPnP and control app
2 channels driven, 20Hz - 20kHz, <0.02% THD 110W/175W
2 channels driven, 1kHz, 0.2% THD 125W/190W
7 channels driven, 1kHz, 0.2% THD 90W/110W
Residual noise & hum (A-wtd) <0.15mV
Stereo Line Inputs
Maximum input 4.5V rms
Nominal sensitivity 1V, 2V, 4V (user adjustable)
Input impedance 47kΩ
Signal/noise ratio (A-wtd ref 100W) normal/stereo direct 100dB/110dB
Frequency response 20Hz—20kHz ± 0.2dB
Nominal output level 1V RMS (max. 5V RMS)
Output impedance 560Ω
THD+N (20Hz—20kHz) –100dB
Maximum output level into 32Ω 5Vrms
Output impedance <100Ω
Mains voltage 110–120V or 220–240V, 50–60Hz
Power consumption (maximum) 1.5kW (Thermal dissipation approx. 5200 BTU/hour)
Power consumption (idle, typical) 100W (Thermal dissipation approx. 340 BTU/hour)
Power consumption (standby) <0.5W
Dimensions W x D (including speaker terminals) x H (including feet) 433 x 425 x 171mm
Weight (net) 16.6kg
Weight (packed) 19.9kg
3 x WiFi/Bluetooth antennas
