Rotel Michi X3 Integrated Amplifier
Rotel Michi X3 Integrated Amplifier
Couldn't load pickup availability
- Free Delivery
- Demo Available
- Trade-in Available
Share
Details
Description
The Michi X3 Integrated Amplifier delivers uncompromised audio performance conveniently packaged in an elegant industrial design. The X3 delivers 350 Watts of Class AB output power into 4 ohm loads maintaining musical accuracy with exceptional acoustic detail from the Analog, Digital, PC-USB, apt-X Bluetooth and Moving Magnet Phono Stage source inputs.
The Michi X3 Integrated Amplifier delivers uncompromised audio performance with a full array of source inputs including Analog, Digital, PC-USB, XLR, apt-X Bluetooth and a Moving Magnet Phono Stage connection for classic vinyl lovers. The X3 is conveniently packaged in an elegant industrial design delivering 350 Watts of Class AB power into 4 ohm speakers while maintaining musical accuracy with exceptional acoustic detail.
Every aspect of the X3 has been custom engineered with all critical circuits and components hand selected through rigorous listening sessions and bench testing. Engineered with over 58 years of audio engineering experience the X3 is sure to bring countless hours of entertainment.
Specifications
Specifications
| Maximum Power Output | 350 watts/channel (4 ohms) |
| Continuous Power Output | 200 watts/channel (8 ohms |
| Total Harmonic Distortion | < 0.008% |
| Intermodulation Distortion (60 Hz : 7 kHz, 4:1) | < 0.03% |
| Frequency Response |
Line Level Inputs: 10Hz - 100kHz (+0dB, -0.4dB)
Digital Inputs: 20Hz - 20kHz (0 ± 0.4dB)
Phono Input: 20Hz - 20kHz (+0dB, +0.4dB)
|
| Damping Factor (20 Hz - 20kHz, 8 ohms) | 350 |
| Input Sensitivity / Impedance | Phono Input (MM): 5.2 mV / 47k ohms Line Level Inputs (RCA): 340 mV / 100k ohms Line Level Inputs (XLR): 540 mV / 100k ohms |
| Input Overload |
Line Level Inputs (RCA): 3.5V
Line Level Inputs (XLR): 5.5V
Phono Input: 60mV
|
| Preamplifier Output Level / Impedance | 1.9 V / 100 ohms |
| Tone Controls | Bass: ±10 dB at 100 Hz Treble: ±10 dB at 10k Hz |
| Signal to Noise Ratio (IHF "A" Weighted) |
Line Level Inputs: 102dB
Digital Inputs: 102dB
Phono Input: 80dB
|
| Channel Separation | Phono Input: > 55 dB Line Level Input: > 55 dB |
| Frequency Response | 20 Hz - 20k Hz (0 ± 0.4 dB) |
| Signal to Noise Ratio (IHF “A” weighted) | 102 dB |
| Input Sensitivity/Impedance | 0 dBFs / 75 ohms |
| Preamplifier Output Level | 1.3 V (at -20 dB Volume Position) |
| Coaxial/Optical Digital Signals | SPDIF LPCM (up to 192kHz 24 bit) |
| PC-USB | USB Audio Class 1.0 (up to 96kHz 24-bit) USB Audio Class 2.0 (up to 384kHz 32-bit)* *Driver installation required DSD and DoP support |
| Power Requirements | Europe: 230 V, 50 Hz USA Power: 120 V, 60 Hz |
| Power Consumption | 500 watts |
| Standby Power Consumption | Normal: < 0.5 watts Network Wakeup: < 2 watts |
| BTU (4 ohms, 1/8 power) | 1303 BTU/h |
| Dimensions (W x H x D) | 485 x 150 x 452 mm 19" x 6" x 17 3/4" |
| Front Panel Height | 132 mm / 5 1/4" |
| Weight (net) | 28.9 kg, 63.7 lb |
| Finish | Black |
