Aurender A20 Analog Music Server/Streamer
Aurender A20 Analog Music Server/Streamer
Couldn't load pickup availability
Share
Details
Description
Signature Analog Music Server
MQA Full-Decoder DAC / Headphone Amplifier
2 x Slot for 2.5″ HDD or SSD Drive (user-installable)
Variable-Output Balanced XLR and Single-Ended RCA Analog Outputs
USB Digital Output / Coaxial and Optical Digital Inputs
Â
A20
Signature sound with Aurender’s best DAC built-in.
Signature Analog Output Network Player with Aurender’s best built-in DAC, dedicated Headphone Section, User-Installable Storage Options, XLR and RCA Analog Outputs
Â
Redefining the relationship between Digital Audio and Music
A20 is derived from A30 and delivers the very same reference-level audio performance, but without the CD ripping and library management functionality. A20 also replaces A30’s factory-fitted 10TB HDD with two user accessible bays to install one or two 2.5” HDDs or SSDs for the music storage capacity needed or desired.
Employing the same renowned dual-mono AKM 4497 chipset as that found in model A30, you can expect nothing but the best in sound quality. A20 is ideal for the user seeking exceptional audio performance from files and streams without the fuss or complexity of separate components.
A20’s scaled back design makes no compromise where audio performance is concerned. Music lovers who have no need for CD ripping functionality and want a high-end DAC without adding more boxes will find A20 to be a stellar foundation to any system.
Â
Key Features
Aurender’s Best DAC
Aurender designed the A20 for those seeking the simplicity of an all-in-one unit without sacrificing a high level of resolution, transparency, and the reproduction of inner detail. Built around an integrated dual-mono AKM4497 DAC module, A20 delivers MQA full-decoding to get the best performance out of MQA content, as well as every other major digital audio format.
Linear Power Supply with Integrated UPS
A fully-linear power supply architecture with extensive shielding prevents noise from being delivered to sensitive DACs. Four discrete toroidal transformers power the server system, digital outputs and dual-mono DAC respectively. A “super capacitor” based UPS system stabilizes A20 in the event of an abrupt loss of power.
FPGA-Based Precision Clock
A20’s precision clock generation system incorporates a Field-Programmable Gate Array (FPGA) with sub 100fs jitter-reducing clock generator to precisely time digital audio data transmissions and minimize jitter to below negligible levels.
Variable Output XLR & RCA Outputs
A20’s high quality Balanced (XLR) and Unbalanced (RCA) outputs guarantee compatibility with any preamp, integrated amp, or even power amps! A20’s DAC-level lossless volume control enables it to function as a preamp when connected directly to a power amplifier.
Dedicated Headphone Section
In addition to being a stellar Analog Output Network Player for loudspeaker systems, A20 also features a 1/4″ headphone output for quiet times.
Upsampling DAC Option
A20 is capable of upsampling non-DSD files up to 705.6/768kHz to the analog outputs. Or leave upsampling off (default setting) for an untouched bitstream.
User-Installable Storage Options
A20 is built with two trays for user-installable storage. Need a lot of capacity? Load up to 2 8TB SSDs! Not into storing files and prefer to stream? Leave them empty, and don’t pay for storage capacity you won’t use.
Digital Connectivity
Four digital inputs are provided: one RCA Coax, one BNC Coax and two Optical. These inputs allow connection of additional digital sources such as a CD transport, TV, etc. Any device connected this way will take full advantage of the superior sound quality of the DAC within the A20.
Specifications
Specifications
| Dimensions (W × D × H) | 16.9″ × 14″ × 4.4″ (3.9″ without feet) |
| Weight | 31.3 lbs |
| Chassis Material | Machined Aluminum |
| Front Panel Display | 8.8″ Wide IPS Color LCD, 1920 × 480 Resolution |
| Power Supply | Full Linear Design; 1 Ă— 50W (CPU), 2 Ă— 25W (DAC L/R), 1 Ă— 35W (FPGA & Headphone) |
| CPU | Intel Low-Power Quad-Core |
| RAM | 8 GB |
| Library Storage Capacity | 2 × 2.5″ User-Installable Drive Compartments |
| System & Cache Storage | 480 GB NVMe SSD |
| Data USB Ports | 2 Ă— USB 3.0 (Rear) |
| Software Suite | Aurender Conductor |
| Ethernet Port | Double-Isolated Gigabit LAN |
| UPS | Yes (Super Capacitors) |
| Power Consumption | 47W (Play), 80W (Peak), 6W (Standby) |
| CD Ripping Capability | N/A |
| Analog Outputs | XLR (Balanced), RCA (Unbalanced) |
| DAC Chipset | AKM 4497 Dual-Mono |
| Audio Word Clock | OCXO |
| Analog Output Format Support | PCM up to 768 kHz / 32-bit, DSD512 (Native) |
| Digital Output | Dedicated USB Audio Output |
| USB Audio Output Format Support | PCM up to 768 kHz / 32-bit, DSD512 (Native), DSD256 (DoP) |
| SPDIF / AES-EBU Output Support | N/A |
| Digital Inputs |
1 Ă— Coaxial RCA 1 Ă— Coaxial BNC 2 Ă— Optical (Toslink) |
| Headphone Output | 1 × 6.5 mm (1/4″) Unbalanced |
| Master Clock Input | N/A |
| MQA Support | Full MQA Decoder On Board |
| Supported Audio Formats | DSD (DSF, DFF), WAV, FLAC, AIFF, ALAC, M4A, APE, and others |
| DSD-to-PCM Conversion | N/A |
