    B.dpr EX

    DAC / PREAMPLIFIER / STREAMER / SERVER

    Enhanced version of the B.dac EX, the B.dpr integrates an additional 100% analog pre-amplification stage built with components of the highest quality. Digital losses are by construction non-existent, and the conversion circuits are used at their optimal operating point.

    The B.dpr EX features analog, balanced and coaxial inputs allowing the connection of up to 3 additional analog sources.

    Full elimination of source jitter

    The B.dpr EX features our patented SJR “Source Jitter Removal” technology which provides the best possible D/A conversion, from every source, by fully eliminating all imput jitter without the need of external clock link. The pre-amplification stage is done by a relay-driven resitor network that avoids any interference on the signal.

    Design

    Reflecting its exclusivity the B.dpr EX relies on a modern and sleek design featuring a machined aluminium front panel with integrated ball-bearing mounted rotary knobs.

    Network functionalities

    The available features include:
    – access to streaming services (Qobuz, Tidal, Spotify …) via compatible iOS and Android applications
    – compatibility with protocols UPnP, MPD, LMS, NAA, Roon, Airplay, Spotify
    – playback of various formats: PCM up to 384kHz / DXD / DoP / native DSD up to DSD 256
    – integrated UPnP server (makes data stored on USB media accessible over the network)

    Analog inputs

    The B.dpr features two unbalanced inputs (RCA) and one balanced input (XLR). Thanks to the analog volume control stage, the signals coming from these inputs are processed completely in the analog domain.

    Acoustic correction

    The onboard DSP features parametric acoustic correction to help make the most of the room and speakers. In-house developed, this functionality is based on a 64-bit architecture. The overall gain is determined automatically without user intervention, which guarantees the absence of saturation regardless of the parameters used. These specific features preserve the signal quality, thereby ensuring an optimal result.

    Remote control

    Each B.dpr EX comes with a custom-made remote control made of massive aluminium.

    SPECIFICATIONS

    GENERAL
    Power supply Factory set : 220-230V or 100-115V, 50-60Hz
    Dimensions 450x375x91mm
    Weight 7,4kg
    TECHNICAL
    Power stage total capacity > 80 000µF
    Power stage regulation custom designed
    Conversion type multibit sigma-delta
    Clock management patented SJR technology
    STREAMER / SERVER
    Connectors 1x RJ45, 1x USB DATA
    Streaming protocols UPnP, MPD, LMS, NAA, Roon, Airplay
    access to streaming services (Qobuz, Tidal, Spotify, …) via compatible iOS and Android applications
    Supported formats PCM up to 384kHz / DXD / DoP / native DSD up to DSD 256
    gapless playback with compatible control applications
    Integrated music server UPnP / Openhome compliant
    ACOUSTIC CORRECTION
    Architecture 64-bit DSP
    Specifications 8x parametric filters with automatic gain adjustment
    DIGITAL IN
    Connectors 2x SPDIF, 2x Toslink, 1x AES/EBU, 1x USB (type B)
    USB (type B)
    operating mode asynchronous
    Supported format PCM (incl. DXD), DSD, DSD over PCM (DoP)
    Sample rate (PCM) 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz (DXD), 384kHz
    Word length (PCM) 16, 24, 32 bits
    Data rate (DSD) 2.8224MHz (DSD64), 5.7648MHz (DSD128), 11.2896MHz (DSD256)
    Data rate (DSD over PCM) 2.8224MHz (DSD64), 5.7648MHz (DSD128)
    SPDIF and AES/EBU
    Supported format PCM
    Sample rate (PCM) 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
    Word length (PCM) 16, 24 bits
    Toslink
    Supported format PCM
    Sample rate (PCM) 44.1kHz, 48kHz, 88.2kHz, 96kHz
    Word length (PCM) 16, 24 bits
    ANALOG IN
    Balanced
    Connectors 1x XLR
    Input impedance 47 kOhms
    Unbalanced
    Connectors 2x RCA (pair)
    Output impedance 47 kOhms
    ANALOG OUT
    Balanced
    Connectors XLR
    Output impedance 100 Ohms
    Unbalanced
    Connectors RCA
    Output impedance 75 Ohms
    VARIABLE OUTPUT LEVEL
    Balanced -80 to +0 dB, 64 steps
    Unbalanced -80 to +0 dB, 64 steps
