Details
Description
3-way passive loudspeaker with bi-wiring capability, housed in a 4-chamber natural slate cabinet, known for its low resonance and finishable in either natural surface (SN) or custom lacquer (SL)
The material and the technology make the difference
Building speakers with cabinets made of natural slate is logical.
Its layered structure, its low resonance and its extremely high mass content give the material exceptional acoustic properties that cannot be achieved with other materials in loudspeaker construction.
The commonly used vibration-sensitive wooden speaker cabinets drain energy from the speaker chassis by causing the cabinet walls to vibrate.
In slate cabinets, however, the entire energy of the loudspeaker is available for air excitation.
The audible consequence:
more dynamics and level in the bass reproduction.
The visible aesthetic advantage:
smaller, living space-friendly housing dimensions.
The energy balance of natural slate is not only outstanding in the bass range. The material's extreme inertia means that the amplitudes of vibrating dome membranes in tweeters are not compensated by the resonating baffles. Here, too, this results in significantly more nuanced and impulsive music reproduction.
The color tone also makes a difference: In addition to the natural slate version, you can also give each box your own personalized color. Sanded and painted in any RAL or automotive color.
Our commitment to achieving the highest level of sound quality is also based on consistent development work and sound technology.
To meet this requirement, we use components and chassis from the absolute top producers on the world market.
Craftsmanship and technical perfection as well as continuous development, including of existing products, guarantee the owner of every FISCHER & FISCHER loudspeaker a very high level of value retention.
This means that even after years, it is still possible to have the loudspeaker updated to the latest state of the art.
Hear the difference and enjoy a truly natural sound experience with a timeless, aesthetically pleasing object.
Specifications
Specifications
| Feature | Specification |
|---|---|
| Frequency response (+/- 3 dB) | 24 - 27000 Hz |
| Impedance | 4 Ohm |
| Sensitivity | 92 dB (1 W / 1 m) |
| Max. acoustic pressure | 112 dB |
| Frequency dividing network | 1st + 2nd order phase and impedance corrected filter. Optimized, selectively separated crossovers |
| Function principle | bass reflex |
| Bass system | two 220 mm FISCHER & FISCHER cone speakers with carbon paper foam sandwich membrane |
| Midrange system | two 180 mm FISCHER & FISCHER cone speakers with carbonized paper, carbon foil sandwich membrane and aluminium phaseplug |
| Treble system | one FISCHER & FISCHER Air Motion Transformer (AMT), special custom made by Mundorf |
| Connecting terminal | Bi-wiring, 63 A connecting terminals, rhodium plated |
| Dimensions slate cabinet (H x W x D) | 1245 x 275 x 400 mm |
| All over dimensions, incl. floor system | 1290 x 380 x 455 mm |
| Floor system | aluminium, black or silver anodized, levelable |
| Weight | 115 kg |
| Cabinet material | 20 / 23 mm thick low resonance natural slate |
| Cabinet design | Low-resonance natural slate cabinet, 4-chamber system. Natural slate (SN) or polished and varnished, available in any RAL colour. |
