The B.dac one incorporates our patented SJR “Source Jitter Removal” technology. It provides optimal conversion quality, even from sources subject to a significant level of jitter, regardless of the input (USB, AES-EBU, SPDIF or TOSLINK optical).
Design
Adopting the refined aesthetics typical of B.audio products, the B.dac one features a visually screwless enclosure, which includes a massive CNC machined aluminum front panel fitted with an OLED display housed in a glass window.
Power supplies
Like our reference models, the B.dac one has a dual power supply that separates the digital domain from the analog domain. The transformers are sized accordingly to ensure perfect operating stability.
Oversampling
The B.dac one uses a linear phase digital filtering system that has been optimized to prevent pre-echo phenomenon and guarantees an optimal transient response. This oversampling process is embedded in a DSP that employs in-house developed algorithms.
Output stage
The B.dac one features a 100% balanced analog output stage with low-phase deviation filters like our reference converters.
|
GENERAL |
||
| Power supply | Factory set : 220-230V or 100-115V, 50-60Hz | |
| Dimensions | 450x375x91mm | |
| Weight | 6,9kg | |
| TECHNICAL | ||
| Power stage total capacity | > 45 000µF | |
| Power stage regulation | multiple, linear | |
| Conversion type | multibit sigma-delta | |
| Clock management | patented SJR technology | |
| DIGITAL IN | ||
| Connectors | 2x SPDIF, 2x Toslink, 1x AES/EBU, 1x USB (type B) | |
| USB (type B) | ||
| operating mode | asynchronous | |
| Supported format | PCM (incl. DXD), DSD, DSD over PCM (DoP) | |
| Sample rate (PCM) | 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz (DXD), 384kHz | |
| Word length (PCM) | 16, 24, 32 bits | |
| Data rate (DSD) | 2.8224MHz (DSD64), 5.7648MHz (DSD128), 11.2896MHz (DSD256) | |
| Data rate (DSD over PCM) | 2.8224MHz (DSD64), 5.7648MHz (DSD128) | |
| SPDIF and AES/EBU | ||
| Supported format | PCM | |
| Sample rate (PCM) | 44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz | |
| Word length (PCM) | 16, 24 bits | |
| Toslink | ||
| Supported format | PCM | |
| Sample rate (PCM) | 44.1kHz, 48kHz, 88.2kHz, 96kHz | |
| Word length (PCM) | 16, 24 bits | |
| ANALOG OUT | ||
| Balanced | ||
| Connectors | XLR | |
| Output impedance: | 100 Ohms | |
| Unbalanced | ||
| Connectors | RCA | |
| Output impedance: | 75 Ohms |
