Bowers & Wilkins HTM81 D4 Centre Speaker
Bowers & Wilkins HTM81 D4 Centre Speaker
Couldn't load pickup availability
- Free Delivery
- Demo Available
- Trade-in Available
- 5 year Warranty
Share
Details
Description
Our largest center-channel speaker is designed to partner the 801 D4 and 802 D4. A powerful performer, it has both the scale and the midrange extension to perfectly match the quality of its illustrious stablemates. *Stand(s) not included.
At the center of it all
Aerofoil bass cone
Our Aerofoil bass cone technology remains an outstanding solution to the conundrum of combining low mass and high stiffness in bass cones, thanks to its carbon-fiber skin and variable-profile foam core. Now, we have added the foam Anti-Resonance Plug for lower distortion and even cleaner bass.
Diamond dome tweeter
One of our most significant accomplishments over the past two decades, the ultra-stiff, supremely accurate Diamond dome tweeter is the perfect combination of low mass, exceptional stiffness and outstanding accuracy. 15 years after we introduced it, we haven’t found a better tweeter dome technology.
Aluminum bass pods
HTM81 D4 mounts two Aerofoil bass cones in twin solid aluminum bass pods, each of which is clamped into an aluminum plate fixed to the stiffest part of its curved cabinet. Formed as single pieces of metal, these stiff structures provide the perfect mechanical location for those powerful bass cones.
The science of sound
Innovation is at the heart of everything we do. We question, we examine, we understand and then we evolve. We use computer modelling to explore and reimagine every aspect of loudspeaker design. Learn more about all the technologies that combine to make 800 Series Diamond so special here.
Bowers and Wilkins largest centre-channel Speaker is designed to be the perfect partner for the 801 and 802 D4. Small wonder, then, that it’s such a powerful performer, with a sound that perfectly matches the quality of its illustrious stablemates.
Inside the HTM81 D4, Bowers and Wilkins use a stiff aluminum enclosure, designed to maximise the performance of the midrange drive unit. It provides a controlled location point for the midrange decoupling and prevents unwanted air leakage into the surrounding cabinet.
Nintronics will have the full 800 D4 series on demonstration, so feel free to give us a call on 01707 320 788 or drop us an email at sales@nintronics.co.uk to book an appointment or discuss our fantastic trade-in incentives.
Specifications
Specifications
| Technical features | Diamond tweeter |
| Solid body Tweeter-on-Top | |
| Continuum cone FST™ | |
| Anti-Resonance plug | |
| Biomimetic Suspension | |
| Matrix™ | |
| Aerofoil cone bass units | |
| Flowport™ | |
| Description | 3-way vented-box system |
| Drive units | 1x ø25mm (1in) diamond dome high-frequency |
| 1x ø150mm (6in) Continuum cone FST™ midrange | |
| 2x ø250mm (8in) Aerofoil cone bass units | |
| Frequency range | 20Hz to 35kHz |
| Frequency response (+/-3dB from reference axis) | 28Hz to 28kHz |
| Sensitivity (on axis at 2.83Vrms at 1m) | 90dB |
| Harmonic distortion | 2nd and 3rd harmonics (90dB, 1m on axis) |
| <1 % 80Hz – 20kHz | |
| <0.3% 100Hz – 20kHz | |
| Nominal impedance | 8Ω (minimum 3.0Ω) |
| Recommended amplifier power | 50W – 500W into 8Ω on unclipped programme |
| Max. recommended cable impedance | 0.1Ω |
| Dimensions | Height: 334mm |
| Width: 847mm | |
| Depth: 371mm | |
| Net weight 32.20kg |
