Details
Description
The F1-10S builds upon the original and critically acclaimed F1-10. Distilling Fyne Audio’s decades of Hi-Fi point source loudspeaker expertise into a design of breath-taking acoustic performance, the F1-10S is an eye-watering beauty. Dr Paul Mills and his development team have reimagined the crossover and upgraded the 250mm (10″) IsoFlare driver to include FyneFlute technology. Combined with the twin cavity BassTrax ported cabinet, the result is an enhanced bass reaching down to 26Hz. Featuring a 75mm titanium dome compression tweeter, the 10” IsoFlare driver offers a seamless, time aligned HF response to over 26kHz for ultimate realism and listener engagement. The F1-10S’s very high sensitivity (94dB/W ensures exceptional dynamic range and compatibility with the widest range of amplifiers from single ended triode valve models to the highest power solid state designs. The BassTrax porting and high quality potentiometer controls for HF energy and presence ensure the F1-10S will deliver optimum performance irrespective of room size or placement. Designed, hand crafted and hand finished at Fyne Audio’s UK manufacturing facility the sumptuous lacquered burr walnut finish of the F1-10S offers a bold statement in loudspeaker design for the audiophile.
Specifications
Specifications
| Specifications | |
|---|---|
| System Type | 2 way, downwards firing port with BassTrax Tractrix diffuser |
| Recommended Amplifier Power (Watt RMS) | 20 - 280 |
| Peak Power Handling (Watt) | 500 |
| Continuous Power Handling (Watt RMS) | 140 |
| Sensitivity (2.83 Volt @ 1m) | 94dB |
| Nominal Impedance | 8 Ohm |
| Frequency Response (-6dB typical in room) | 26Hz - 26kHz |
| Drive Unit Complement | 1 x 250mm IsoFlare point source driver with FyneFlute surround, multi-fibre bass / midrange cone, with 75mm titanium alloy dome compression tweeter, neodymium magnet system |
| Crossover Frequency | 750Hz |
| Crossover Type | Bi-wired passive low loss, 2nd order low pass, 2nd order high pass, Deep Cryogenically Treated |
| System Adjustments | High frequency energy (750Hz - 26kHz) +/-3dB Presence (2.5kHz - 5.0kHz) +/- 3dB |
| Dimensions (H x W x D) | 1191 x 405 x 581mm (46.9 x 15.9 x 22.9”) |
| Net Weight (Each) | 57.7kg |
| Finishes | Piano Gloss Walnut |
| S-Trax Position (from cabinet front edge) | 108mm (4.3") |
| SuperTrax Position (from cabinet front edge) | 84mm (3.3") |
