Details
Description
M stands for Micro-line, the design of the nude diamond stylus tip used on this range of two cartridges, the ML (low output) and MH (high output).
The Hana M Series cartridge bodies are made from black polyoxymethylene (POM) which is a very hard, extremely rigid and very strong thermoplastic Excel using a particular formulation of POM manufactured by DuPont that sells under the trademarked name ‘Delrin’. Both cartridges have nude Microline styluses and aluminium cantilevers. The shape of the nude Microline stylus, mimics that of the cutting stylus used in the cutting lathe and therefore fits precisely into the vinyl groove.
Specifications
Specifications
- Stylus: Nude Microline
- Cantilever: Aluminium
- Magnet: Alnico
- Coil Wire: Very High Purity Copper
- Cartridge Housing/Base: POM/Brass
- Output Level: 0.2mV (ML)
- Output Level: 2.0mV (MH)
- Channel Balance: <1dB/1kHz
- Rec. Tracking Force: 2g
- Trackability: 70µ/2g
- Compliance: 10×10-6 cm/dyne
- Channel Separation: 30dB @ 1kHz
- Frequency Range: 12Hz to 45kHz
- Impedance: 8Ω (ML)
- Impedance: 100Ω (MH)
- Suggested Load Impedance: <100Ω (ML)
- Suggested Load Impedance: 47kΩ (MH)
- Cartridge Weight: 9.5g
- Body Colour: Black
