Marantz
Marantz Amp 20 12 Channel Power Amplifier
Marantz Amp 20 12 Channel Power Amplifier
Couldn't load pickup availability
Share
Details
Description
AMP 20
Reference 12 Channel Amplifier with 200W and Exclusive HDAM
AMP 20 is a remarkably powerful 12-channel amplifier, and can be paired with AV 20 for an elite, reference-level home theater system.
- Crafted in Shirakawa, Japan
- 12 Channels
- 200 Watts per Channel
- Exclusive HDAM
- Custom Switching Amplifiers
- Selectable Output Modes
Ultimate Performance
AMP 20
AMP 20’s custom-developed Class D amplification and refined HDAM-SA2 technology create the most incredible theatrical experience possible in your home.
Our Marantz Sound Master meticulously tuned AMP 20 for amazing performance with careful parts selection to create outstanding sound in your home.
AMP 20 gives you 12 channels of commanding power in a single enclosure, each rated at 200 watts to perform at extraordinarily high levels with no loss in fidelity.
Make sure you get the best possible performance from your AMP 20 by combining it with other Marantz products – such as the AV 20.
Specifications
Specifications
| Inputs / Outputs | |
|---|---|
| Main Amplifier In | Balanced & Unbalanced: 12ch (Exclusive use by a selector switch.) |
| Speaker Terminal | SPKT-1+ |
| Number of Speaker Terminals | 12 |
| Bi-Amp Drive / BTL Drive | Yes / Yes |
| Level Meter | Yes |
| Chassis | Copper Plated |
| RS232 Control | Yes |
| IR Flasher In | Yes |
| Marantz Remote Bus | Yes |
| DC Trigger Input / Output | 1 / 1 |
| Specifications | |
| Number of Power Amps | 12 |
| Power Output (8 ohm, 1 kHz, 0.05% 2ch Drive) Normal / BTL | 200W / 400W |
| Power Output (4 ohm, 1 kHz, 0.7% 2ch Drive) Normal | 400W |
| Power Output (8 ohm, 1 kHz, 0.7% 5ch Drive) Normal | 200W |
| General | |
| Front Display | Level Meter |
| Auto Power Off | Yes |
| Metal Front Panel | Yes |
| Power Consumption | 400W |
| Power Consumption, No-Sound | 110W |
| Standby Consumption | 0.2W |
| Maximum Dimensions (W × D × H) | 17.4 × 17.4 × 7.5 in. |
| Weight | 39.7 lbs |
| What's in the Box | Main unit, quick start guide, AC cord, Amp control cable, Remote control cable, SP terminal wrench |
