Marantz
Marantz MODEL 10 Reference Integrated Amplifier
Marantz MODEL 10 Reference Integrated Amplifier
Couldn't load pickup availability
Share
Details
Description
MODEL 10
Reference Integrated Amplifier with 250W and All-New Marantz SMPS
MODEL 10 is the new reference in amplifier design. Featuring a newly designed dual-mono symmetrical amplifier topology, it is the most powerful, highest performing Marantz amplifier ever.
- 2 Channels
- 250 Watts per Channel
- All-New Marantz SMPS
- Fully balanced dual mono amplifiers
- Phono MM/MC
- Copper-plated chassis
Specifications
Specifications
| General | |
|---|---|
| Unit (W × H × D mm) | 440 × 192 × 473 |
| Cabinet Size | 440 × 192 × 422 |
| Net weight | 33.7kg |
| Packaging Dimensions (W × H × D mm) | 600 × 379 × 540 |
| Packaging gross weight | 39.0kg |
| Carton Color | 1 Color (Material color: Brown Printing: Black) |
| Panel Color | Black / Marantz Champagne |
| Front (Center) Panel | Anodized machined aluminum |
| Back-shell | Anodized machined aluminum |
| Front panel illumination | Yes (All sides, Dimmer) |
| Side cover | Aluminum (Thickness: Max 15.8mm) |
| Top cover | Aluminum (Thickness: 6mm) |
| Top cover (Center) ventilation hole material | Stainless mesh |
| Interior illumination | Yes, dimmable |
| Rear Panel | Copper Plated |
| Chassis Material | Copper Plated |
| Bottom Layer / Bottom plate | Triple layer Copper plated |
| Volume Knob | Solid aluminum (Bearing construction) |
| Input Selector | Solid aluminum (Bearing construction) |
| Foot | Solid Aluminum Copper plated (H: 18.5mm) |
| Heatsink for Power Amplifier | Extruded Aluminum |
| Audio | |
| Rated Output Power | 250W + 250W (8Ω, 20Hz-20kHz, THD 0.05%) 500W + 500W (4Ω, 20Hz-20kHz, THD 0.05%) |
| Speaker Impedance | 4~16Ω |
| Frequency Response | 5Hz~60kHz (+0dB / -3dB) 20Hz~20kHz (+0dB / -0.3dB) |
| Total Harmonic Distortion | 0.005% (125W, 8Ω, 20-20kHz) (CCIF IMD, DFD IMD) |
| Damping Factor | 500 (8Ω, 20Hz-20kHz) |
| Input Sensitivity (Phono) | MM: 3.6 mV / 36 kΩ MC (Low): 400 μV / 33Ω MC (Mid): 400 μV / 100Ω MC (High): 400 μV / 390Ω |
| RIAA Deviation | 20 Hz - 20 kHz ±0.5 dB (MM/MC) |
| Phono Maximum Input | MM: 80mV MC: 8mV |
| Input Sensitivity (CD/LINE/RECORDER) | 350 mV / 41kΩ (Unbalanced) 700 mV / 36kΩ |
| Input Sensitivity (Power Amp input) | Unbalanced: 1.58V / 41kΩ (Gain: 29dB) Balanced: 3.16V / 15kΩ (Gain: 24dB) |
| SN Ratio | PHONO (MM): 88dB PHONO (MC): 76dB CD: 122dB Balanced: 122dB |
| Headphone Output Level | 130mW / 32Ω |
| Tone Control | BASS: 50Hz ±10dB TREBLE: 15kHz ±10dB |
| Power Consumption | 270W 0.1W (at Standby) |
| Audio / Video | |
| Phono Input | Yes (MM / MC) Marantz Musical Premium Phono EQ with Selectable MC impedance (3 positions) |
| Analog Input (include Phono) / REC Out (RCA) | 4 / 1 (LINE1, LINE2, PHONO: Thick nickel plated independent terminals) (RECORDER: Thick nickel plated independent terminals) |
| Balanced XLR Input | 2 |
| Power Amp Direct | Yes [RCA / XLR] |
| Pre Out | Yes [RCA / XLR] |
| 2 sets of Speaker Output | Yes (Bi-wiring) |
| Speaker Terminal | Marantz Original SPKT-100+ (2) High quality and high-purity copper plated |
| Headphone Output | 1 (Turns off the speaker automatically when headphone is inserted) |
| Control / Other | |
| Remote Control Bus Terminal | Yes (RC-5 In / Out) |
| Remote Internal / External Switch | Yes |
| Flasher Input | Yes |
| AC Inlet | Yes |
| Other | F.C.B.S. (Floating Control Bus System) |
| Remote Controller | 10 series Universal Remote control |
| Unit control (Button) | Tact Switch: 1 (POWER) |
| Unit control (Knob) | 2 (VOLUME, INPUT SELECTOR) |
| LED | POWER: 1 White Protection: 1 Orange Illumination (Edge): White Interior: White |
| Front Panel Display | New HD TFT Color Display |
| Dimmer for Front Display | 20 steps |
| Level meter | Yes (HD Display) |
| Volume Display | -infinity / -99.5dB to 0dB (0.5 step) 0–100 / 0.5 step (switchable) |
| Last Function Memory | Yes |
| Auto Standby Mode | Yes |
| Remote Controller | RC004PMND |
| Battery | Yes (AAA ×2) |
| Power Cord | Yes (ALL region / Audio Grade / OFC) |
| Other | CoA card |
