Mark Levinson 5802 Integrated Amplifier
Mark Levinson 5802 Integrated Amplifier
Couldn't load pickup availability
- Free Delivery
- Demo Available
- Trade-in Available
- 5 year Warranty
Share
Details
Description
Mark Levinson № 5802 Integrated Amplifier: Pure Power, Detailed Sound.
Experience the very essence of the artist's performance with the Mark Levinson № 5802. This meticulously engineered integrated amplifier combines a high-performance preamplifier and a robust Class A/B power amplifier within a single, stunningly designed component. Prepare to rediscover your digital music collection with dynamic, vibrant, and powerfully pure sound.
Key Features:
- Detailed Digital Audio: Uncover new nuances in your digital library thanks to the integrated Precision Link II Digital-to-Analog Converter (DAC), which accurately reproduces audio signals and minimizes unwanted noise. Enjoy exceptional clarity and detail across your entire digital music collection.
- Virtually Distortion Free Power: The № 5802's pristine Class A/B amplification and highly capable power supply (500+ VA toroidal transformer) deliver abundant power to your loudspeakers, effortlessly filling your room with rich, distortion-free sound, even at high volumes.
- High-Performance Headphone Output: Immerse yourself in a truly personal listening experience with the dedicated Class A analog headphone stage. Unleash the full potential of your high-performance headphones and lose yourself completely in the music's intricacies.
- Convenient Bluetooth Audio Input: Enjoy seamless, high-quality wireless playback from your Bluetooth-enabled devices with the integrated receiver featuring aptX HD support.
- Luxurious and Iconic Design: The № 5802 is a statement piece, boasting a gently curved profile and a beautiful glass front panel, meticulously crafted to exude timeless excellence and luxury.
- Flexible Control Options: Take command with the intuitive Mark Levinson 5Kontrol app or the included aluminum remote. Effortlessly integrate the № 5802 into your smart home ecosystem with a variety of connection options.
- Comprehensive Digital Connectivity: Featuring a wide array of digital inputs including AES, USB 2.0, coaxial S/PDIF (x2), and optical S/PDIF (x2), supporting high-resolution audio up to 384 kHz/32 bit PCM and DSD 11.2 MHz.
- MQA Full Decoding: Experience studio-quality sound from MQA (Master Quality Authenticated) encoded files across all digital inputs, including asynchronous USB.
- Designed and Handcrafted in the USA: Ensuring exceptional quality and meticulous attention to detail.
- EuP Compliant / Low-Power Standby: Designed with energy efficiency in mind.
The Mark Levinson № 5802 is more than just an amplifier; it's a gateway to experiencing your music with unparalleled purity, detail, and emotional impact.
Specifications
Specifications
Mark Levinson No. 5802 Integrated Amplifier Specifications
Digital Inputs:
- 1 x AES/EBU XLR
- 1 x USB 2.0 (Type-B, asynchronous)
- 2 x Coaxial S/PDIF RCA
- 2 x Optical S/PDIF Toslink
- Bluetooth with aptX-HD support
Digital Audio Processing:
- DAC: Precision Link II DAC, ESS Sabre 32-bit
- PCM: Up to 32-bit/384kHz
- DSD: Up to DSD 5.6 (DoP)
- MQA: Full decoding on all digital inputs including USB
- Digital Filters (PCM): Seven user-selectable settings
- Up-sampling: User selectable up-sampling to 352.8/384kHz
Analog Outputs:
- Line Outputs: 1 x RCA stereo (variable)
- Headphone Output: 1 x 1/4-inch / 6.35mm jack (front panel)
- Speaker Outputs: 2 pairs high-current binding posts
Amplifier Section:
- Type: Fully discrete, direct-coupled, Class AB
- Power Output: 125W RMS per channel at 8 Ohms (20Hz - 20kHz)
- Power Output: ~250W RMS per channel at 4 Ohms
- Minimum Impedance: Stable operation down to 2 Ohms
- Frequency Response: <2Hz - 20kHz (+0/-0.2dB), <2Hz - 100kHz (+0/-3dB)
- Signal-to-Noise Ratio: >103dB (20Hz - 20kHz, A-weighted), >100dB (20Hz - 20kHz, wideband, unweighted)
- THD+N: <0.035% at 1kHz, 125W, 8 Ohms; <0.18% at 20kHz, 125W, 8 Ohms
- Output Impedance: <0.098 Ohms (20Hz - 10kHz), <0.11 Ohms at 20kHz
- Damping Factor: >82 (20Hz - 10kHz), >72 at 20kHz (referred to 8 Ohms)
Headphone Output:
- THD: <0.04% (20Hz and 1kHz, 2V RMS output, 30 Ohms load), <0.10% (20kHz, 2V RMS output, 30 Ohms load)
- Output Overload: >3.3V RMS (30 Ohms load)
- Signal-to-Noise Ratio: >91dB (20Hz - 20kHz, A-weighted, referred to 2V RMS output), >87dB (20Hz - 20kHz, wideband, unweighted, referred to 2V RMS output)
- Output Impedance: <2.5 Ohms (20Hz - 20kHz)
Control & Connectivity:
- Ethernet (RJ45) for IP control and software updates
- RS-232 (DB9) for third-party automation
- 12V Trigger Input/Output (3.5mm jack)
- IR Input (3.5mm jack)
- Internal webpage for setup, configuration import/export, and software updates
- Control modules available for Crestron, RTI, Control 4, Savant, AMX, and URC
General:
- Power Supply: Oversized (500+ VA) toroidal transformer with individual secondary windings for left and right channels
- Power Consumption: Max 500W, Green Mode <0.4W, Power Save 7W, Normal Mode 45W (Standby)
- Mains Voltage: Factory set for 100VAC, 115VAC, or 230VAC
- Dimensions (H x W x D): 5.72" (145mm) x 17.25" (438mm) x 19.98" (507mm)
- Weight: 61 lbs (27.6 kg)
- Design: All-new Nº 5000 series industrial design with 1-inch thick aluminum front panel and recessed glass display
- Remote Control: Included custom aluminum IR remote
- Handcrafted in the USA
- EuP compliant / low-power standby
