McIntosh MC2301 Monoblock Power Amp (Each)
McIntosh MC2301 Monoblock Power Amp (Each)
Couldn't load pickup availability
- Free Delivery
- Demo Available
- Trade-in Available
- 3 year Warranty
Share
Details
Description
The new McIntosh MC2301 monoblock tube amplifier hails the fusion of our Unity Coupled and Quad-Differential circuit topologies. The Mcintosh Unity Coupled Circuit stands as one of the premiere tube topologies ever conceived, making possible revolutionary power bandwidth and low distortion. Quad-Differential circuitry, a recent McIntosh innovation, cancels nearly all induced noise and circuit-borne nonlinearities resulting in the lowest noise levels ever achieved in a tube amplifier. With 300 Watts available at 8, 4 or 2 ohms, the MC2301 provides power enough to drive even the most difficult loudspeakers. From the demands of massed chorale to full-on rock and roll, the MC2301 delivers the most extraordinarily lifelike and dynamic performance ever heard from a McIntosh tube amplifier.
- 300 Watts Mono Power Output
- Balanced Design
- Multifilar Wound output Transformers
- Wide Power Bandwidth
- Two Balanced Inputs/Outputs
- Remote Power Control with Meter Light Control
- Low Distortion from 20Hz to 20kHz
- Large Gold Plated Five-Way Binding Posts
- Thick Glass Front Panel with Tube View
- Fiber Optic Light Diffuser Illumination
Power Output
300 watts into an 8, 4 or 2 ohm load is the minimum sine wave continuous average power output.
Specifications
Specifications
| Output load impedance | Terminals for 8, 4 and 2 ohms |
| Rated power band | 20Hz to 20kHz |
| Total harmonic distortion | 0.5% maximum harmonic distortion at any level from 250 milliwatts to rated power output. |
| +0, -0.5dB from 20Hz to 20kHz | |
| +0, -3.0dB from 10Hz to 100kHz | |
| Input sensitivity | 1.7V Unbalanced |
| 3.4V Balanced | |
| A-weighted signal-to-noise ratio | 117 below rated output |
| Intermodulation distortion | 0.5% maximum if instantaneous peak power output does not exceed twice the rated output, for any combination of frequencies from 10Hz to 20kHz |
| Wide band damping factor | Greater than 15 |
| Input impedance | 47,000 ohms |
| Tube compliment | 2 – 12AT7 Voltage Amplifiers; 8 – KT88 or 6550 Output Tube |
| Power requirement | 100 volts, 50/60Hz, 6.6 amps |
| 110 volts, 50/60Hz, 6 amps | |
| 120 volts, 50/60Hz, 5.5 amps | |
| 220 volts, 50/60Hz, 3 amps | |
| 230 volts, 50/60Hz, 2.75 amps | |
| 240 volts, 50/60Hz, 2.75 amps | |
| Standby 1W | |
| Dimensions (HxWxD) | 12-5/16” (31.3cm) x 17-3/4” (45.1cm) x 23” (58.4cm) |
| Weight | 116 pounds (52.6kg) net: 141 pounds (64kg) in shipping carton |
