Monitor Audio

Monitor Audio CI Amp IA60-4

Monitor Audio CI Amp IA60-4

Regular price £1,150.00
Regular price Sale price £1,150.00
Sale Sold out
  • Pay in 3
View full details

Details

Description

A highly compact, incredibly versatile four-channel custom installation amplifier, the IA60-4 can be configured to deliver four channels of 60 W or 2 channels at 125 W.

Monitor Audio Installation Amplifiers are built to perform at the highest levels while taking up the least rack space. The IA60-4 may be entry-level, but it features full DSP matrix configuration and offers flexible power options: it can be configured to deliver four channels of 60W or 2 channels at 125 W or using power sharing it can deliver a single channel of 250 W with no loss of performance. All this from a rugged, 1U half-size space-saving design. The IA60-4 is ideal for two zone stereo applications, height channels within home theatre Atmos solutions or small garden systems.

Key Features

  • 4 x 60 W/2 x 125 W
  • Fully customisable DSP amplifier with web configurator
  • Half width 1U rack format allows unique installation opportunities or high power density depending on how the product is mounted
  • High performance Class D amplifiers ensure excellent power and sound delivery
  • Power Sharing technology
  • Supports 70/100V line level speakers

Specifications

Specifications

Channels 4
Output Power @ 4 Ohms/8 Ohms 4 x 60W SE*
Output Power @ 70/100V 2 x 125W BTL**
Poweshare (up to) 1 x 250 W
Power Consumption 75 W
Thermal Output 256 BTU
Polarity (Default) Non-inverting
Dimensions 44 x 220 x 325 mm​ (13/4 x 811/16 x 115/8")
Output Voltage 70Vp / 140Vpp (SE unloaded), 140Vp / 280 Vpp (BTL unloaded)
Signal to Noise Ratio >106dB (A-weighted, 20 Hz – 20 kHz, 8 Ohm load)​
THD+N (typical) <0.05% (20 Hz – 20 kHz, 8 Ohm load, 3db below rated power)​
Frequency Response +0/-0.25dB 20Hz - 20kHz (8 Ohm load, 3dB below rated power)
Protection Circuits Short circuit -, DC, Undervoltage -, Temperature – and Overload protection​
Power Supply Switch mode power supply with Power Factor Correction (PFC) and standby converter
Operating​ Voltage/Frequency Universal Mains, 100 V – 240 V, 50 Hz – 60 Hz​
Standby Consumption <0.5 W
Accessories Rack Mount Kit, Wall/desktop mount kit (sold seperatley)
Power Ratings 1% THD @ 120Vac and 230Vac​
Cabinet Finish Black Anodised
* SE Single Ended
** BTL Bridge Tied Load
*** BTU British Thermal Unit
Warranty 5 years
