Monitor Audio Creator Series W1M In-Wall Speaker (Each)
Monitor Audio Creator Series W1M In-Wall Speaker (Each)
Couldn't load pickup availability
- Pay in 3
Share
Details
Description
This medium-sized Tier 1 in-wall loudspeaker is a two-way model featuring two C-CAM mid-bass drivers and a C-CAM tweeter. It has a cut-out dimension of 527 x 198mm and revolutionary patented Quick-Link speaker cable connector and Tri-Grip II for quick, simple, reliable and strong installation and fitting.
This medium-sized Tier 1 in-wall loudspeaker is designed for cost-effective installations, where product simplicity and solid acoustic performance is required. It is a two-way model featuring a C-CAM mid-bass driver and C-CAM tweeter. The performance benefit of having both within a single design means greatly improved clarity, wider dispersion into the listening environment, and clear lifelike high-fidelity sound – of the quality you’d expect from any Monitor Audio passive box loudspeaker. It has a cut-out dimension of 527 x 198 mm and uses the patented Quik-Link speaker cable connecter, which revolutionises the ease and speed of speaker installation. Tri-Grip has also been evolved for simple, reliable and strong fitment.
Key Features
- Ideal for cost-effective installations, where product simplicity and solid acoustic performance is required
- Two-way design
- 1 x 1" (25 mm) C-CAM tweeter with UD Waveguide I for lifelike sound
- 2 x 5" (127 mm) C-CAM mid-bass driver for clear mid-range and full bass
- Patented Quik-Link speaker cable connector for quicker installation (UK patent application no. 2216966.8)
- Tri-Grip II for easy and secure fitment
Specifications
Specifications
| System Format | 2–Way |
| Channels | 1 |
| Frequency Response, Installed (-6dB) | 40 Hz – 30 kHz |
| Nominal Impedance | 6 ohm |
| Minimum Impedance (20Hz to 20kHz) | 4.8 Ohm @ 15 kHz |
| Sensitivity (2.83Vrms@1m, Installed) | 87 dB |
| Maximum Peak SPL* (single speaker @ 1m Z-Weighted) | 113 dB |
| Continuous Power Handling (RMS into Nominal Impedance, Pink Noise with 6dB Crest Factor) | 75 W |
| Recommended Amplifier Power (RMS into 8 OHM, Music Signal) | 30 – 110 W |
| Drive Unit Complement | 2 x 5" (127 mm) C-CAM mid-bass driver 1 x 1" (25 mm) C-CAM tweeter |
| Crossover Frequency | LF/HF: 2.75 kHz |
| Mounting Depth | 85 mm (33/8") |
| Cutout L x W | 527 x 198 mm (203/4 x 713/16") |
| External Dimensions (Including Grille (H x W x D)) | 560 x 231 x 90 mm (221/16 x 91/8 x 39/16") |
| Weight (each) | 3.4 kg (7 lb 8 oz) |
| Pre-Construction Bracket | WM-B |
| Cabinet Finish | Matte black & Orange |
| Sold As | Single Unit |
