Roksan

Roksan Caspian Vinyl System Control (VSC)

Name: Roksan Caspian Vinyl System Control (VSC)
Brand: Roksan
SKU: Caspian Vinyl System Control
Price: 3525.0 GBP
Availability: InStock

£3,525.00

Sale Sold out

Tax included. Shipping calculated at checkout.

Product variants

Quantity

Trade in Available Book a Demo

Free Delivery
Demo Available
Trade-in Available
5 year Warranty

View full details

Details

Description

For ultimate convenience and a fully comprehensive solution for getting the best performance from your Xerxes Turntable, the VSC unit combines both a RPM speed control and RPP phono stage in a single chassis.

The VSC also powers the Xerxes Turntable, it has one reference DS1.5 linear power supply for both RPM and RPP sections.

(The VSC can be upgraded to VSC2 specification as an after-purchase option)

Key Features

VSC with a single DS1.5 PSU module
Ultimate control and convenience for the Xerxes Turntable in one box
Combines reference MM/MC phono stage with reference speed control
VSC is upgradeable to VSC S2

Specifications

Power Supply

VSC — DS1.5 x 1

Output Voltage (RPM)

16 V RMS (33 and 45 RPM)

Phase (RPM)

0 degrees and 90 degrees

DC Offset (RPM)

<10 mV

Harmonic Distortion (RPM)

<0.1 %

Output Impedance (RPM)

<0.1 ohms

Gain Settings (RPP)

MM: 40.6 dB @ 1 kHz
MC1: 56 dB @ 1 kHz
MC2: 65.5 dB @ 1 kHz

Signal to Noise Ratio (RPP)

MM: >89dB (ref. 5.0 mV)
MC1: >79dB (ref. 5.0 mV)
MC2: >70 dB (ref. 5.0 mV)

Harmonic Distortion (RPP)

<0.01 %

Overload Margin (RPP)

26 dB all settings

Output Impedance (RPP)

< 50 ohms
